Enerpac Hydraulic Cylinder, High Tonnage Load Return Lock Nut Single Acting Solid Plunger, 113 ton, 5.31 in Bore, 11.81 in Stroke, 17.2 in Retract, Base Mount, 3/8-18 NPTF, 2.8 in Rod Dia, 10000 psi, Steel Housing, 6.89 in OD x 29.02 in H

ITEM FEATURES:

• Lock nut provides positive and safe mechanical load holding
• Low friction locking rings spin easy, save time and effort
• Designed to withstand 10% side load up to 90% of maximum stroke
• Hardened surface resists side loading and cyclic wear
• Overflow port as stroke limiter to prevent plunger blow-out
• Weather protected, inside and out
• Replaceable bearings enclose the plunger for support throughout the stroke
• Certified lifting eyes and base mounting holes
